Automatic Spacer Bending Machine, highly versatile, is equipped with a head which bends not only Aluminium but also stainless steel and plastics(option). The automatic feeding system delivers up to 6 m long bars directly from storage. Bending is performed with high-quality accuracy, ensuring a continuous connection of the spacers and controlling the right length of frame. The machine can bend straight and free shapes up to 2500 x 2500 mm (For bigger sizes, the machine will bend in 2 steps, automatically).

All the system are controlled by touch screen(±0.3mm)

Numerically controlled equipped with feeding servo motor

Device for automatic detecting spacer width.

Device for sucking in aluminum spacer dreg

Auto Connection with spacer

Spacer Size: 6mm ~ 21mm/ 4Step Station

Automatic/Manual Mode

Feeding Speed:40m/min

Automatic loading and connection

Operator friendly design

Precise transfer spacer using patented conveyor method

Easy controllable of all tools with touch screen and PLC program

Possible to recode monitoring current production quantity and easy operation

Self-diagnosis and alarm Function

Print function (optional)
